SMA Sunny Boy Storage: Easily retrofit battery storage to your existing solar

sunny boy storage

The Sunny Boy Storage. A low(ish) cost way to add a Powerwall and other batteries to your existing solar system. Image: SMA

The SMA Sunny Boy Storage is a battery-inverter that you can use to add battery storage to your existing rooftop solar system.

It does not store energy itself, but integrates modern battery packs, such as the Tesla Powerwall, into your home’s electricity supply. It is exciting because it is the cheapest and simplest way to add a battery such as the Powerwall to your existing system. This is because it can re-use your existing inverter – no need to replace it.

It is compatible with any inverter because it is AC coupled. This means it simply connects into your existing solar inverter‘s 240V AC output.

It takes this AC power and converts it into DC power to charge your batteries:

The Sunny Boy Storage Charging

The Sunny Boy Storage charging

And when the batteries discharge it converts their DC into the AC used by the home:

SMA SBS discharging

And discharging.

The Sunny Boy Storage is the best priced battery-inverter on the market that I can find. It comes with a 10 year warranty. It is able to output a maximum of 2.5 kilowatts of AC power, below the maximum output of most battery storage systems. These systems could still be used with the Sunny Boy Storage, but not at their full power. The average efficiency of the Sunny Boy Storage at converting current is around 96.5%, which is very good.

It is for on-grid use only and cannot currently be used to give backup power from your batteries during a black out. A retrofit kit making this possible will be available later this year, but it is likely to be a substantial extra cost and will not be compatible with some inverters.  The Sunny Boy Storage is due to be released in Australia in August 2016.

The Sunny Boy Storage’s Vital Statistics

 [wpdtable id=”6194″]

Are You Sure You Want Batteries?

Let’s say you have an existing, on-grid, rooftop solar system and you want to add battery storage to it. Well, the very first thing you need to do is have your head examined, because at the moment battery storage is still very expensive and cannot pay for itself anywhere in Australia. Not even in Canberra and the city of Adelaide which have battery subsidies.

However, if after your head has been thoroughly examined, you decide you want to install batteries for non-economic reasons, or, you think the hole in your head makes you look stylishly attractive, then read on.

Batteries Don’t Help The Environment

People can want to install batteries for a variety of reasons, but at the moment, helping the environment is not a good one. This is because when you charge and discharge a battery, some power is always lost . So sending one kilowatt-hour of solar electricity directly into the grid will cut fossil fuel use by more than using one kilowatt-hour of stored solar electricity.

In the future, as renewable generating capacity expands, home energy storage could help cut greenhouse gas emissions, but at the moment this is not the case. Not even in South Australia which has the most wind and solar power in the country. When the situation changes, I’ll let you know.

The exception to this is if your rooftop solar system is export limited, which means you are not allowed to export all the surplus solar electricity you generate and so some goes to waste. This most often happens in rural areas. In this case, using battery storage can definitely be an environmental plus.

How AC Coupling Works

Solar panels on your roof will generate DC current during the day. Even if it is cloudy they will still produce some power. This gets sent to your solar inverter which transforms the DC current from the panels into the AC current your home uses. If you have microinverters instead, the situation is similar, except you have many small inverters instead of one large one.

The Sunny Boy Storage comes with its own mini power meter, placed on the wire that connects your home to the grid. This meter tells the Sunny Boy Storage if your home is exporting or importing electricity at any moment in time. 1

The easiest way to add storage to this is to attach a battery-inverter, such as the Sunny Boy Storage, to the output of your solar inverter. The battery system is connected to the Sunny Boy Storage and it should look like this:



sunny boy storage line diagram

How the Sunny Boy Storage is retrofitted to your existing system via AC Coupling

This setup is called AC coupling because the Sunny Boy Storage is coupled, or connected, to a cable that carries AC power. When the household produces more solar electricity than it is using, the Sunny Boy Storage will take AC power from this cable and convert it into the DC batteries need to charge. And when the household is using more power than its rooftop solar provides, the Sunny Boy Storage will take DC from the batteries and convert it to AC for use in the home.

The advantage of this system is that the Sunny Boy Storage doesn’t need to communicate with the inverter. They have nothing directly to do with each other, so it doesn’t matter what kind of inverter the rooftop solar system has. As long as the inverter works, you can add batteries with a Sunny Boy Storage.

The Sunny Boy Storage Doesn’t Do DC Coupling

There is another way to attach batteries to a rooftop solar system. That is to use the DC power produced by solar to charge the batteries. Then wire the battery directly into the solar inverter for your DC-to-AC conversion. There is no place for the Sunny Boy Storage in this sort of arrangement. DC coupling is not its bag, baby.

The disadvantage of DC coupling is it needs a special hybrid solar inverter which costs more than a conventional one. And it  also must be compatible with your battery system and able to communicate with it. While this can be arranged when installing a completely new rooftop solar system, for an existing system it would require replacing the solar inverter it has now, which might still have many years of life left in it, and replacing it with an expensive hybrid solar inverter.

The advantage of DC coupling is the overall efficiency will be higher than with AC coupling.

The Sunny Boy Storage And Efficiency

Unfortunately, some energy is lost when the Sunny Boy Storage converts AC into DC to charge the battery and when it converts DC from the battery into AC. Fortunately, the Sunny Boy Storage’s efficiency at converting is quite high and averages 96.5%. This loss will apply when it both charges and discharges the battery.

This loss of energy will be on top of what is lost by the battery. So if the Sunny Boy Storage is used with a Tesla Powerwall, with a claimed efficiency of 92.5%, then the system efficiency would be around 86.1%. If used with the LG Chem RESU battery system with an efficiency of 95%, the overall efficiency would be 88.5%.

The Sunny Boy Storage’s Power Is Not High

The amount of electrical energy stored in batteries is measured in kilowatt-hours. The rate at which batteries can supply stored energy is called power and is measured in kilowatts. No matter how much power the battery system has, the amount of power the Sunny Boy Storage can supply is quite limited.

The Sunny Boy Storage can give a maximum 2.5 kilowatts of AC power. That’s not a lot. There are oven elements that draw 2.4 kilowatts. And that’s just for using the oven and not the grill or any hotplates. So with one of those oven elements you couldn’t even roast a turkey and play Xbox at the same time without exceeding the Sunny Boy Storage’s power limit. You could probably watch TV, provided the show was slow paced and not too exciting. (That’s how TV energy consumption works, right?)

This means when the solar panels aren’t producing power, any electricity consumption over 2.5 kilowatts will have to come from the grid. This is regardless of how many kilowatt-hours of energy you may have socked away in your batteries or how much power they could supply if only the Sunny Boy Storage wasn’t electron-blocking them.

The 2.5 kilowatts maximum the Sunny Boy Storage supplies is less than many battery systems can offer. The Tesla Powerwall can give a continuous 3.3 kilowatts of power, while the LG Chem RESU provides 3.6 kilowatts. Not being able to reach their full potential won’t harm your batteries and will actually help to extend their life. But it is still a major pain in the economic butt. It can make it difficult to use all your stored energy overnight. It can also make it very difficult to use it all during peak pricing periods on time of use tariffs.

Making The Sunny Boy Storage Smarter With The Sunny Boy Home Manager

When I described how the Sunny Boy Storage integrates into an existing rooftop solar system and how it must communicate with an extra mini electricity meter, I actually described a situation that is pretty dumb. Not dumb as in it won’t work, or there is a better way to arrange the basic set up, but dumb as in not very smart. As in the system can’t know you may want to save your stored energy for peak electricity price periods, or that you want to charge the batteries with off-peak grid electricity.

But this is fixed by installing the Sunny Boy Home Manager which will communicate with the Sunny Boy Storage and SMA mini Energy Meter and allow you to intelligently monitor, control, and plan your energy use. It has a one year warranty and by itself is likely to cost over $600.

Operating Temperatures

The Sunny Boy Storage’s operating temperature is from -40 to 60 degrees Celsius. So unless you take it down to the Australian Antarctic Territory, you can be confident it will never conk out due to being too cold. And provided it is kept out of direct sunshine it should never shut down on account of excess heat.

Warranty

The Sunny Boy Storage has a 10 year warranty which is the same as the warranty of many battery systems.  However, because of the nature of the beast, battery storage rarely lasts a great deal longer than its warranty, but quality inverters often do. So I don’t think it is unreasonable to expect your Sunny Boy Storage to easily outlive its battery storage.

Compatible Battery Systems

Just which battery systems the Sunny Boy Storage is compatible with is a very important question, and so far  SMA  have answered that it is compatible with the Tesla Powerwall and that is it. But other compatible systems will be announced. Obviously, it is in their interest to make it compatible with as many systems as possible, and they have indicated it could potentially work with any lithium-ion battery system, but just whether it will work with the non-Tesla energy storage system you may happen to have your eye on, I cannot say. At this point all that can be done is wait for clarification.

Retrofitting The Sunny Boy Storage To Provide Back Up

Currently the Sunny Boy Storage will not let you use your batteries during a black out. If the grid fails then you will be left sitting in the dark no matter how many kilowatt-hours you may have stored.

However, towards the end of the year, SMA will make a retrofit kit available for the Sunny Boy Storage that will allow your batteries to give backup power during a grid outage.

This might sound like a great idea, but it is important to remember that at a maximum output of 2.5 kilowatts, the Sunny Boy Storage will not let you live as though the grid is still working. In addition to getting the retrofit kit installed, you are likely to also need your switchboard rewired, so only certain loads such as lights and refrigeration will run off battery power. But the good news is if you have the Sunny Boy Home Manager it should make managing your power use easier.

At What Price?

The Sunny Boy Storage is likely to cost under $2,000.  But exactly what it will cost to install is very difficult to judge. This is because very few people are likely to say to an installer, “I just want a Sunny Boy Storage. I don’t want any batteries or anything. I just want a battery-transformer installed that is completely useless to me.” Rather, it will be part of a package deal including a battery system, an SMA Energy Meter, and an optional Sunny Boy Home Manger.

If you are very fortunate and get an excellent deal, you may get a Sunny Boy Storage and a battery system such as a Tesla Powerwall installed for as little as $10,000.  But at the moment, you are likely to have to pay considerably more, so be ready for your wallet to feel a lot lighter after this process.

The Sunny Boy Storage Is One of The Best Ways To Add Battery Storage

For those want to install energy storage to an existing rooftop solar system, the Sunny Boy Storage should definitely be one of the simpler ways to do it. However, be aware that its low power output can make the economics of installing on-grid battery storage worse than they already are.

Footnotes

  1. This meter costs about $500 – which seems like a total waste, when your existing meter is already doing a great job of measuring your power. Unfortunately the retailers won’t let anyone except their own devices talk to the meter that they charged you hundreds for. So you need to splash out $500 on an extra meter. SMA could also get the same result with 2 x $10 Current Transformers, one on the inverter output and one on the house input, but they’ve gone for the gold-plated option of a $500 meter
About Ronald Brakels

Joining SolarQuotes in 2015, Ronald has a knack for reading those tediously long documents put out by solar manufacturers and translating their contents into something consumers might find interesting. Master of heavily researched deep-dive blog posts, his relentless consumer advocacy has ruffled more than a few manufacturer's feathers over the years. Read Ronald's full bio.

Comments

  1. Chris Thaler says

    Question, is this system suited for single phase only or also capable of fitment to a three phase installation?

    • Finn Admin says

      Yes it is capable of 3 phase installation – but your battery will only be able to discharge into one phase:

      SMA Sunny Boy Storage on 3 phase solar system

  2. If you already have a Sunny Boy + Sunny island setup could you add the sunny boy storage to hook up an 2nd battery?

  3. “Well, the very first thing you need to do is have your head examined, because at the moment battery storage is still very expensive and cannot pay for itself anywhere in Australia.”

    How many thing in life do you buy that pay itself off???

    I can’t believe you work in the solar industry.

    • Ronald Brakels says

      I’m not going to lie and tell people that installing battery storage in an on-grid home pays for itself or provides an environmental benefit because at the moment it does not pay for itself and is an environmental negative.

      In my personal opinion wasting money on something that harms the environment is nuts. Especially when people could instead do things that benefit both their wallets and the environment instead, such as installing or expanding rooftop solar, insulating their homes, buying a bicycle and using it instead of a car, installing a heat pump hot water system or solar hot water, replacing old inefficient fridges and plasma TVs, installing rooftop solar on grandma’s roof, and so on.

      In the article I mentioned the one situation in which battery storage is currently an environmental plus.

      It may not be long before home energy storage does pay for itself and when that happens I’ll let you know. And it maybe not be too long after that it will start to provide an environmental benefit. And I will also let you know when that happens.

      Now if someone wants to install battery storage for non-economic and non-environmental reasons they are perfectly free to do so, but I’m not going to lie and tell them they will save money or directly benefit the environment.

      I tell jokes now and then, but if you want me to lie to you the only way that will happen is if you marry me.

  4. Tom Martin says

    Ron, Thanks for this honest review and witty commentary. I have a home in Hawaii, which had recently stopped offering NEMS and seems to be one of those export limited situations for rooftop Solar. In that circumstance, what would you recommend in regards to battery storage?
    Thanks

    • Ronald Brakels says

      Tom, looking up Hawaii’s electricity prices I get a figure of 33 US cents. That’s about 45 Australian cents and considerably higher that what we pay even in South Australia. I don’t know what it costs to get battery storage installed in Hawaii, but if installation costs are around the same as in Australia then it is quite possible it could save you money – provided you aren’t getting anything for your surplus solar electricity. If excess electricity from your rooftop solar is just going into the grid and your meter isn’t turning back and you aren’t getting paid for it, or worse, you are export eliminated and the surplus electricity is just going to waste, then batteries could save you money. If the electricity is going to waste then installing home battery storage can be an environmental plus, which it normally isn’t.

      Sorry I don’t know enough about conditions in Hawaii to tell you anything definite. But maybe you should consider getting a Redflow ZCell. It’s designed in Australia and made in Mexico and Hawaii is located between the two, so maybe that means it will be perfect for you?

      • Tom Martin says

        Electricity was 43 cents /kwh (US) a few years ago when fuel was more expensive. Currently, Oahu and Big Island are close to their “grid supply” cap. With “grid supply”, they reimburse at about 1/2 current retail rate. Once capped, the utilities will not give new solar installs anothing for electricity exported to grid. The latter is what they term “self supply”. At least “self supply” allows you to import electricity, it is not “off grid”. This new policy is severely hurtihg solar installation business in Hawaii. I hope that the utilities change to system like Colorado and California, which kept NEMs but with TOU and reimburse based on TOU rates. That gives solar over producers an incentive to install batteries to use power later during peak demand time or export to grid at a higher reimbursement rate. It is a win-win system for all.

  5. Tom Martin says

    Ron,
    Any comment on Goodwe BP, a battery charge controller that can connect battery to inverter? I read that with solaredge inverters, you can only connect one string from inverter to Goodwe BP. Solaredge just released their Storedge module, which will connect batteries (only Powerwall and LG Chem so far) to both strings of Solaredge inverters (DC-DC) and up to 2 batteries. It can be retrofit to certain SE inverters.

  6. Ron this was written a year ago and I hear there has been a dramatic drop in battery prices so does gustimate of $10 still apply

    • Ronald Brakels says

      I saw offers for installed battery storage using what looked like a Sunny Boy Storage for under $10,000 but they appear to have disappeared. If that’s your price range, you can certainly get battery storage installed for under that much. The Enphase AC battery comes to mind. But you won’t get a lot of capacity for that much. If you believe the price Tesla gave, than at some point, you will be able to get the 13.5 kilowatt-hour Powerwall 2 installed for $10,150. But in my personal opinion, I doubt you’ll be able to get a system installed for that much. At least not any time soon.

      At the moment, no on-grid battery system will pay for itself under anything close to normal circumstances.

  7. John Muller says

    I plan better use of our 2.6kW of solar panels with an LG RESU10 battery charged by a 2.5kW SunnyBoy Storage inverter. At midday on a good winters day the output of our P/V panels peaks at about 1.2kW, nowhere near the nominal 10amp capacity of the Storage inverter, so the battery will trickle-charge all day.
    Is this acceptable practice and will the battery tolerate it?

    • Ronald Brakels says

      Charging slowly should be better for the battery than charging it quickly. It’s just a pity you often won’t be able to fully charge it in winter. Or any day with a significant amount of cloud for that matter.

  8. Ziyad Saeed says

    Will you review the larger version with blackout backup capability.

  9. sunny Island is still far better…shifting power price from peak to off peak with no solar panels required…pays for itself much quicker too.

  10. Kim Andersen says

    Hi..
    I´m seaking some advice/help on this battery inverter.

    I have a solar system 6.6kW solar system where the SMA Sunnyboy Storage is connected and a LG Chem Resuh 10H batteri.
    I´m worried that the SMA inverter has never been setup correctly, so it´s deep charging the battery every day. But I have not idea where to change this in the Sunny Boy inverter setup.. I have read the manual, and do have connection to the paramters allright. I just need to know, exactly where to look and perhaps change this setting.

    Can anyone guide or advice me.. The system was setup in 2017.. So I guess it´s time to do some serious investigation about this before damaging the battery totally. Unfortunatly the knowledge in these things are limited in Denmark, and SMA is very bad to communicate with private consumers.

    Greets
    Kim..
